Center laminated plastic film backsheet for big waistband diaper supplier
The center laminated breathable film is a component often used in the construction of products like diapers or incontinence pads. This material is engineered to provide both breathability and liquid resistance. It plays a critical role in ensuring that the product performs well in terms of leakage prevention while still allowing air to pass through, which is crucial for maintaining skin health.
Material :
Polyethylene +PolypropyleneBasic weight :
23-100 gsm, CustomizedWidth :
70-2200 mm, CustomizedColor :
Customized，1-8 colorsOuter roll diameter :
460mm-580mm, CustomizedProduction process :
Casting and LaminationHardness :
SoftPrinting :
CustomizedUsage :
BacksheetApplication :
Baby diaper, adult diaper, sanitary napkinPacking details :
In the roll, inside with paper core, wrapping by transparent film and paper board; Strandard export packingPayment terms :
T/T, L/C at sight, DP at sightDelivery time :
7-15 days after receipt of the deposit or L/CMinimum order quantity :
1000.00kgsProduct Description
The breathable layer of the partial lamination backsheet film can effectively discharge moisture, prevent the baby's skin from prolonged contact with moisture, and reduce the occurrence of diaper rash and other skin problems. The center laminated plastic film backsheet allows air to circulate, keeping the inner layer of the diaper dry and comfortable, thereby improving comfort. The central composite membrane in diapers significantly improves the performance of diapers by virtue of its leakage resistance, breathability, comfort and durability, ensuring baby's comfort and dryness, reducing skin problems and extending use time. It is an integral part of modern diaper design, ensuring efficient absorption, convenient use and long-term dryness.
Product Attributes
| Items | Unit | Requirement | Result | Judging | ||
| Basic weight | gsm | 24±2 | 24.2 | OK | ||
| Width | mm | 320±2 | 320.5 | OK | ||
| Tensile strength | MD | N | ≥14.0N | 21.37 | OK | |
| CD | ≥5.0 | 7.8 | OK | |||
| Breaking elongation | MD | % | ≥30 | 64 | OK | |
| CD | ≥30 | 88 | OK | |||
| Peel force | MD | N | ≥0.3N/25mm | 1.04 | OK | |
| CD | ≥0.3N/25mm | 1.11 | OK | |||
| Anti hydrostatic pressure | Pa | ≥6000 | 6224 | OK | ||
| Corona | dyne | ≥38 | 38 | OK | ||
| Breathability | g/24h/㎡ | 1500-3200 | 2247 | OK | ||
| Material was suitable to use in hygiene product. | ||||||
Product Application
The printing center laminated film is the key raw materials for diapers making, which can be used in the production of baby diapers, adult diapers, disposable nursing pads and sanitary napkins.
Factory Workshop
The central composite film of diapers is mainly made of materials such as PE film, and the breathable film layer is centrally bonded to the non-woven fabric layer through a specific process. The design of this composite film not only achieves the function of preventing leakage, but also maximizes the softness and breathability of diapers, reducing damage to the skin during infant use.
Lab & Testing
Our factory has a professional R&D technical team, industry-leading production capacity and technology. The raw materials are double-verified to control the quality from the source, reducing the trial and error costs of overseas customers and ensuring stable quality.
Related Products
Our products cover spunbond nonwoven, SMMS hydrophobic nonwoven, thermal nonwoven, hot air nonwoven, frontal tape, side tape, fluff pulp, sap, hot melt glue, spandex and other raw materials for baby diaper, sanitary napkin, adult diaper, underpads and pull up diapers. You can contact us for more details.
Warehouse
We have a modern warehouse of over 10,000 square meters, providing customers with “one station” services, which can mix load different kinds of raw materials, which can help our customers to reduce cost.
Packing & Shipment
Our integrity, strength and product quality are recognized by the industry, and our products are also exported to Southeast Asia, Africa, South America and so on. We firmly believe that with a professional and capable service team and an integrity-based business philosophy, we will continue to create and output value for our customers, and will be able to work hand in hand with our partners to create a brilliant future.
Our Service
1. Cost analysis and cost reduction plan for the entire set of raw materials for finished products
2. One-stop procurement service for hygiene products raw materials
3. Free safety inventory in large warehouses and free consolidation of multiple materials
4. Provide a complete set of process reports and photos for orders
5. Monthly analysis report on the Chinese raw material market
6. Technical support for equipment
7. Raw material process solutions
8. Design and customization of special edition raw materials
