Waist lamination nonwoven hydrophobic hot airthrough fabric for pull-up diapers
Hydrophobic hot air nonwoven fabric belongs to the category of hot air bonded (hot-rolled, hot air) non-woven fabrics. Hot air non-woven fabric is a type of non-woven fabric produced by using hot air from a drying device to penetrate the fiber web after it has been combed, allowing it to be heated and bonded together.
Material :
ES fiberBasic weight :
16-30gsm, CustomizedWidth :
CustomizedColor :
WhiteOuter roll diameter :
580-760mm, CustomizedProduction process :
Airthrough bondingType :
HydrophobicUsage :
Backsheet, Waistband nonwoven for pull-up pants, BarrierApplication :
Baby diaper, adult diaper, sanitary napkinPacking details :
In the roll, inside with paper core, wrapping by transparent film and paper board; Strandard export packingPayment terms :
T/T, L/C at sight, DP at sightDelivery time :
7-15 days after receipt of the deposit or L/CMinimum order quantity :
1000.00kgsProduct Description
The surface of the diaper air through hydrophobic nonwoven presents a smooth and delicate texture, with a soft and comfortable touch that does not cause irritation or friction to the skin. After special water repellent treatment, hydrophobic hot air nonwoven fabric can effectively block moisture infiltration, prevent urine leakage, keep the inside of the pull-up pants dry and clean, and provide a better user experience for babies. Despite its water repellent properties, the white hot air plain weave water repellent non-woven fabric still maintains good breathability. The hot air process creates a strong bond between non-woven fibers, while maintaining good elasticity and resilience, making it less prone to deformation or damage.
Product Attributes
| Items | Unit | Requirement | Result | Judging | |||
| Min | Max | ||||||
| Color | / | white | white | OK | |||
| Basic weight | gsm | 18±2 | 16.5 | 19.5 | OK | ||
| Width | mm | 315±2 | 313 | 317 | OK | ||
| 3D- Dimensional Thickness | mm | 0.3-0.6mm | 0.43 | 0.52 | OK | ||
| Tensile strength | MD | N/5cm | ≥22 | 25.9 | 31.6 | OK | |
| CD | ≥4.0 | 4.8 | 5.4 | OK | |||
| Breaking elongation | MD | % | ≥20 | 53.6 | 62.4 | OK | |
| CD | ≥30 | 97.9 | 117 | OK | |||
| Splice | pcs | ≤1 | 0 | 1 | OK | ||
| Column limit | mm | ≤5 | / | / | OK | ||
| End side plane(even)limite | / | Even | OK | ||||
Product Application
The waist laminated waterproof hot air nonwoven is the key raw materials for diapers making, which can be used in the production of baby diapers, adult diapers, disposable nursing pads and sanitary napkins.
Factory Workshop
Hydrophobic air through bonded nonwoven uses advanced hot air technology to melt and interweave fibers into delicate plain weave, followed by special water repellent treatment to ensure waterproofing while not losing breathability. This process endows non-woven fabric with a soft touch and excellent performance, suitable for high-end hygiene products such as baby pull-up pants, ensuring the dryness and comfort of baby skin.
Lab & Testing
Our factory has a professional R&D technical team, industry-leading production capacity and technology. The raw materials are double-verified to control the quality from the source, reducing the trial and error costs of overseas customers and ensuring stable quality.
Related Products
Our products cover spunbond nonwoven, SMMS hydrophobic nonwoven, thermal nonwoven, hot air nonwoven, frontal tape, side tape, fluff pulp, sap, hot melt glue, spandex and other raw materials for baby diaper, sanitary napkin, adult diaper, underpads and pull up diapers. You can contact us for more details.
Warehouse
We have a modern warehouse of over 10,000 square meters, providing customers with “one station” services, which can mix load different kinds of raw materials, which can help our customers to reduce cost.
Packing & Shipment
Our integrity, strength and product quality are recognized by the industry, and our products are also exported to Southeast Asia, Africa, South America and so on. We firmly believe that with a professional and capable service team and an integrity-based business philosophy, we will continue to create and output value for our customers, and will be able to work hand in hand with our partners to create a brilliant future.
Our Service
1. Cost analysis and cost reduction plan for the entire set of raw materials for finished products
2. One-stop procurement service for hygiene products raw materials
3. Free safety inventory in large warehouses and free consolidation of multiple materials
4. Provide a complete set of process reports and photos for orders
5. Monthly analysis report on the Chinese raw material market
6. Technical support for equipment
7. Raw material process solutions
8. Design and customization of special edition raw materials
