Hot airthrough white plain hydrophobic backsheet lamination nonwoven fabric adult diaper
White nonwoven air through fabric laminated is usually a fiber web composed of thermoplastic synthetic fibers, which is reinforced by hot air bonding. These fibers may include polyester, nylon, polypropylene, etc., which have good thermoplasticity and processability and are suitable for use in hot air bonding processes.
Material :
ES fiberBasic weight :
16-30gsm, CustomizedWidth :
CustomizedColor :
WhiteOuter roll diameter :
580-760mm, CustomizedProduction process :
Airthrough bondingType :
HydrophobicUsage :
Backsheet, Waistband nonwoven for pull-up pants, BarrierApplication :
Baby diaper, adult diaper, sanitary napkinPacking details :
In the roll, inside with paper core, wrapping by transparent film and paper board; Strandard export packingPayment terms :
T/T, L/C at sight, DP at sightDelivery time :
7-15 days after receipt of the deposit or L/CMinimum order quantity :
1000.00kgsProduct Description
The diaper air through hydrophobic nonwoven, as the bottom material of adult diapers, is treated with advanced hot air technology. Laminated waterproof hot air nonwoven not only has excellent waterproof performance, effectively preventing urine leakage, but also maintains the delicate texture of plain weave, enhancing the comfort of wearing. At the same time, the bottom layer is also compounded with another layer of non-woven fabric, further enhancing the structural stability and absorption capacity of the diaper, ensuring that it remains dry and comfortable for long-term use, and is an indispensable key component of adult diapers.
Product Attributes
Items | Unit | Requirement | Result | Judging | |||
Min | Max | ||||||
Color | / | white | white | OK | |||
Basic weight | gsm | 18±2 | 16.5 | 19.5 | OK | ||
Width | mm | 315±2 | 313 | 317 | OK | ||
3D- Dimensional Thickness | mm | 0.3-0.6mm | 0.43 | 052 | OK | ||
Tensile strength | MD | N/5cm | ≥22 | 25.9 | 31.6 | OK | |
CD | ≥4.0 | 4.8 | 5.4 | OK | |||
Breaking elongation | MD | % | ≥20 | 53.6 | 62.4 | OK | |
CD | ≥30 | 97.9 | 117 | OK | |||
Splice | pcs | ≤1 | 0 | 1 | OK | ||
Column limit | mm | ≤5 | / | / | OK | ||
End side plane(even)limite | / | Even | OK |
Product Application
The waterproof hot air nonwoven for backsheet is the key raw materials for diapers making, which can be used in the production of baby diapers, adult diapers, disposable nursing pads and sanitary napkins.
Factory Workshop
The material of adult diaper hot air nonwoven lamination fabric is mainly composed of thermoplastic synthetic fibers, low melting point bonding fibers or two-component fibers, and waterproof coatings. These materials are processed through specific techniques and structures to give non-woven fabrics excellent water repellent properties, soft and comfortable hand feel, and good structural stability. They are very suitable as bottom materials for adult diapers and other hygiene products.
Lab & Testing
Our factory has a professional R&D technical team, industry-leading production capacity and technology. The raw materials are double-verified to control the quality from the source, reducing the trial and error costs of overseas customers and ensuring stable quality.
Related Products
Our products cover spunbond nonwoven, SMMS hydrophobic nonwoven, thermal nonwoven, hot air nonwoven, frontal tape, side tape, fluff pulp, sap, hot melt glue, spandex and other raw materials for baby diaper, sanitary napkin, adult diaper, underpads and pull up diapers. You can contact us for more details.
Warehouse
We have a modern warehouse of over 10,000 square meters, providing customers with “one station” services, which can mix load different kinds of raw materials, which can help our customers to reduce cost.
Packing & Shipment
Our integrity, strength and product quality are recognized by the industry, and our products are also exported to Southeast Asia, Africa, South America and so on. We firmly believe that with a professional and capable service team and an integrity-based business philosophy, we will continue to create and output value for our customers, and will be able to work hand in hand with our partners to create a brilliant future.
Our Service
1. Cost analysis and cost reduction plan for the entire set of raw materials for finished products
2. One-stop procurement service for hygiene products raw materials
3. Free safety inventory in large warehouses and free consolidation of multiple materials
4. Provide a complete set of process reports and photos for orders
5. Monthly analysis report on the Chinese raw material market
6. Technical support for equipment
7. Raw material process solutions
8. Design and customization of special edition raw materials
